TIPPERS
TATA LPK 2821.K FE+ RMC
GVW
152KW @ 2.200 R/MIN
Power5 L Turbitrinn 2.0
Engine7490 Kgs
Deck LengthTATA LPK 2821.K FE+ RMC
Engine
5 L Turbitrinn 2.0
Torque
700 Nm @ 1000 - 1600 r/min
Fuel Tank
Tyres
295/95D20 (Nylon Tyres)
Warranty
Driveline 6 year 6 000 hour | Vehicle 3 year 3 000 hour
Applications
Real State, Concrete Roads (NHAI / Muncipal Roads), Metro projects, Dams / Canal Works, Infra Projects (Aiports), Tunnel Projects
| Load Body Length | 17 Ft |
| Warranty | Driveline 6 year 6 000 hour | Vehicle 3 year 3 000 hour |
| Transit mixe size | 7m3 |
| Wheelbases | 3 880mm |
| Tyre | 295/95D20 (Nylon Tyres) |
| Cabin | New Generation Comfort Cabin |
| Chassis Frame (DxWxT) | 285 x 65 x (7+7)mm |
| Front Suspension | Semi Elliptical Leaf Spring |
| Rear Suspension | Bell Crank |
| Rear Tyre | 7.50 R 16, 16 PR |
| Front Tyre | 7.50 R 16, 16 PR |
| Max Power | 152KW @ 2.200 R/MIN |
| Gearbox | GB-750 |
| Clutch Type | 380 mm |
| Fuel Type | Diesel |
| Fuel Tank Capacity (Litres) | 90 L |
| Gradeability (%) | NA |
| Engine Cylinders | 4 Cylinders |
| Engine Type | 5 L Turbitrinn 2.0 |
| Emission Norms | BS6 PH-2 |
| Max Torque | 700 Nm @ 1000 - 1600 r/min |
