Alternate Fuel
TATA LPT/SIGNA 2820.T CNG
A sustainable CNG-powered hauler engineered for versatile logistics operations and lower running costs.
28000 Kg
GVW149 Kw (200HP) @ 2250 Rpm
PowerTata 5.7L SGI BSVI RDE
EngineSIMILAR VEHICLES
TATA LPT/SIGNA 2820.T CNG
The LPT/SIGNA 2820.T CNG delivers cleaner performance for diverse applications including FMCG, cold chain, auto logistics, and tanker operations. Powered by the Tata 5.7L SGI engine and supported by large CNG tank options, it offers extended range, improved fuel efficiency, and dependable uptime. Advanced telematics and drive-mode technologies further enhance fleet productivity and cost control.
Engine
Tata 5.7L SGI
Torque
700 Nm
Fuel Tank
716L, 986L & 1247L Option
Tyre
295/90R20
Warranty
3Year/3L Km
Applications
Industrial Goods, LPG Bullet, Auto Logistics, Cold Chain, FMCG, Textiles, Parcel & Courier, Tanker, Agriculture Goods
| GVW | 28000 Kg |
| No. of Wheels | 10 |
| Wheel Base | 48 | 55 | 68 |
| Load Span | 22Ft | 24Ft | 32Ft |
| Engine | Tata 5.7L SGI BSVI RDE |
| Engine Capacity / Cylinder | 5675 CC / 6 Cylinder |
| Max. Power | 149 Kw (200HP) @ 2250 Rpm |
| Max. Torque | 700 Nm @ 1300-1600 Rpm |
| Clutch Type | 380 mm Single plate dry friction type |
| Gearbox | Tata G750 6 Speed |
| Rear Axle | RA 110 (RA 109 in 68WB) |
| Front Suspension | Parabolic Leaf Spring (Optional - Semi Elliptical) |
| Rear Suspension | Bell Crank with Semi elliptical Leaf Spring |
| Tyre | 295/90R20 |
| Service Brake | Full Air S-Cam with Automatic Adjuster |
| Auxiliary Brake | Exhaust Brake |
| Chassis Frame | Ladder type heavy duty frame |
| Fuel Tank | 55WB = 716L | 68WB = 986L | 68WB = 1247L |
| Cabin | LPT Cowl / Signa Cabin |
| Ventilation | AC |
| Warranty | 3Year/3Lakh Km |
| Trim Levels | EX |
| Key Features | GSA, FE Switch, Mode Shift Advisor, Cruise Control |
