TATA LPT 4932 / SIGNA 4932.T
The Tata LPT/SIGNA 4932.T stands as India’s first 5-axle rigid truck with a 49-tonne GVW, setting new benchmarks in payload efficiency, structural robustness, and cost-optimised logistics.
49000 Kg
GVW239 Kw (320 HP) @2300 rpm
PowerTATA CUMMINS ISBe 6.7 OBD-II (6702cc)
Engine28 ft | 30 ft | 32 ft
Deck LengthSIMILAR VEHICLES
TATA LPT 4932 / SIGNA 4932.T
Designed to deliver higher revenue per trip and improved total cost of ownership, it combines a robust Signa platform, advanced driveline, and connected capabilities for demanding long-haul operations.
Engine
TATA CUMMINS ISBe 6.7 OBD-II (6702cc)
Torque
1100 Nm @ 1100-1700rpm
Fuel Tank
365L HDPE (Plastic tank)
Tyres
295/90R20 Radial tube type
Warranty
6Y/6L on Driveline
Applications
Cement bags, Bulker, Coal, Agriculture goods, FMCG, Market load, Industrial goods
Engine
| Engine | Cummins ISBe 6.7 |
| Type | 6702 CC / 6 Cylinder |
| Power | 239 Kw (320HP) @ 2300 Rpm |
| Torque | 1100 Nm @ 1100-1700 Rpm |
| Fuel Type | Diesel |
| Fuel tank capacity | 365L HDPE |
Transmission
| Gear Box | Tata G1150 9 Speed |
| Clutch | 430 mm Single plate dry friction type |
| Rear Axle | RA 112 |
chassis
| GVW (for rigids) (Kg) | 49000 |
| Wheelbase (mm) | 68 |
| Deck Length | 29Ft / 31.5Ft |
| No. of Tyres | 16 |
| Tyre | 295/90R20 |
| Front Suspension | Parabolic Leaf Spring |
| Rear Suspension | Bell Crank with Semi elliptical Leaf Spring |
| Brake Type | Full Air S-Cam with Automatic Adjuster |
cabin & Comfort
| Cabin Type | LPT Cowl / Signa Cabin |
technology & Warranty
| Key Features | GSA, Auto FE mode, Cruise control, HSA, ATC, | Low viscous oil, RPAS, 4G Telematics |
| Trim Levels | EX, LX |
| Warranty | Drive line - 6Year/6Lakh Km | Vehicle - 3Year/3Lakh Km |
